SHAPER MACHINE – BELT DRIVEN
Preet Lathe® Udyog is always to produce machine with the utmost quality to ensure high accuracy and cost effectiveness as Shaper Machine manufacturer in Batala. We are one of the good manufacturer and offer great shaper machine price. We handpick the material used in the making of the machinery which includes graded cast iron and ISO standard steel.
Our ShaperMachine specifications are as under below:
| Specifications | Shaper Machine Belt Driven | |||||
| Description | Unit | SM20" | SM24" | SM30" | SM36" | SM40" |
| Maximum Working Stroke | inch | 20" | 24 | 30 | 36 | 40" |
| Length Ram without Tool Slide | inch | 42" | 53 | 60 | 67 | 78" |
| Ram Bearing in Column | inch | 26" | 32 | 38 | 42 | 45" |
| Ram Bearing Width | inch | 10½" | 12 | 12½ | 12½ | 14" |
| Tool Slide Traverse | inch | 6" | 8 | 9 | 10 | 11" |
| Maximum Distance from Table to Ram | inch | 15" | 16 | 18 | 20 | 24" |
| Minimum Distance from Table to Ram | inch | 2" | 2 | 2 | 2 | 2" |
| Horizontal Traverse of Table | inch | 20" | 28 | 30 | 32 | 36" |
| No. of Speed | nos | 3 | 4 | 4 | 4 | 4 |
| Length & Width of Cross Slide | inch | 30"x11" | 38x13 | 40x13 | 45x13 | 50"x15" |
| Top Surface of Table | inch | 20"x12" | 25x15 | 30x16 | 36x16 | 40"x20" |
| Size of Base Plate | inch | 50"x22" | 64x23 | 76x26 | 85x28 | 93"x31" |
| Electric Motor Required | HP | 2 HP | 3 HP | 3HP | 5HP | 7HP |
| *Modification on customer request. | ||||||
| *Specifications are subject to change without notice. | ||||||
