SHAPING MACHINE – ALL GEARED
Our Heavy Duty Shaping Machine is designed to meet the requirement of the modern industry. Preet Lathe® Udyog offers Shaping Machine made from close grained cast iron with hardened gears to ensure high efficiency and meet the accuracy standard available at a very economical shaping machine price. Our range is also available in same specifications with optional Hydraulic Shaper Feed Mechanism.
| Specifications | Shaping Machine - All Geared Driven | |||||
| Description | Unit | SMG20" | SMG24" | SMG30" | SMG36" | SMG40" |
| Maximum Working Stroke | inch | 20" | 24 | 30 | 36 | 40" |
| Length Ram without Tool Slide | inch | 42" | 53 | 60 | 67 | 78" |
| Ram Bearing in Column | inch | 26" | 32 | 38 | 42 | 45" |
| Ram Bearing Width | inch | 10½" | 12 | 12½ | 12½ | 14" |
| Tool Slide Traverse | inch | 6" | 8 | 9 | 10 | 11" |
| Maximum Distance from Table to Ram | inch | 15" | 16 | 18 | 20 | 24" |
| Minimum Distance from Table to Ram | inch | 2" | 2 | 2 | 2 | 2" |
| Horizontal Traverse of Table | inch | 20" | 28 | 30 | 32 | 36" |
| No. of Speed | nos | 3 | 4 | 4 | 4 | 4 |
| Length & Width of Cross Slide | inch | 30"x11" | 38x13 | 40x13 | 45x13 | 50"x15" |
| Top Surface of Table | inch | 20"x12" | 25x15 | 30x16 | 36x16 | 40"x20" |
| Size of Base Plate | inch | 50"x22" | 64x23 | 76x26 | 85x28 | 93"x31" |
| Electric Motor Required | HP | 2 HP | 3 HP | 3HP | 5HP | 7HP |
| *Modification on customer request. | ||||||
| *Specifications are subject to change without notice. | ||||||
